TSL AMU2-8HD+ - 4 0 LS Output; 5 Configuration Switch Functions

AMU2-8HD+/3G 12 Issue 1
5.0 Configuration Switch Functions (z12a.hex/z13.mcs FPGA)
ACI code 7.03 (Note:Subject to change)
SWITCH
SECTION
FUNCTION
1 N/U
2 N/U
3 Loudspeaker O/P mute - UP
4 D25 Anlg variable – Up/Fixed - Dwn
5 AES variable –Up/Fixed -Dwn
6** XLR line O/P’s fixed – Up/variable-Dwn
7 Lo Ro-Up/Lt Rt-Dwn
8 Comp out-Up/ SDI - Dwn
** This output on the first pair of the D25 – Analogue output connector.
Note: The calibration, Frame delay (In Dolby mode) and scale type are factory set.
