TSL AMU2-8HD+ - 6 0 General Notes; 7 Specification

AMU2-8HD+/3G 14 Issue 1
7.0
AMU2-8HD+/3G Technical Specifications
Power Supply
Supply Voltage 100 -240V AC @ 50Hz/60Hz +/- 10%
Power Consumption 60 Watts.
Or
Supply Voltage 12V DC
Physical Dimensions
Height 88mm (2RU)
Width 483mm (19”)
Depth 280mm
Weight 3500gm
Input 1 and 2
Connector Type XLR 3 pin. Pin 1 Gnd, Pin 2 hot, Pin 3 cold.
Signal Balanced line level audio.
Frequency Response 30Hz to 25kHz
Impedance >20kΩ
Inputs AES 1, AES 2
Connector Type XLR (F) 3 pin. Pin 1 Gnd,Pin 2 hot,Pin 3co
Standard AES3 (1994) 32, 44.1, 48, 96 KHz
Impedance Balanced110 Ohm.
Inputs AES 1, 2, 3 and 4
Connector type D25
Standard AES3 (1994) 32, 44.1, 48, 96 KHz
Impedance Balanced110 Ohm.
Inputs, HD/SDV (auto sensing)
Connector Type BNC.
Standard SMPTE 259M 4:2:2 component 525/60
or 625/50 with embedded 48kHz audio.
HDSDI (SMPTE 292M) – 720P & 1080i @ 50, 59.94 & 60Hz
(1080p @ 50/59.94/60Hz where
applicable)
Impedance 75ohm
Return Loss <-20dB to 1.5GHz (3GHz TBA)
AUX (Metadata Output)
Connector D9 (RS422)
Remote Control
Connector D9 (RS 422)
