TSL AMU2-8HD+ - Remote Control Connector; RS 422 - D9 Socket

AMU2-8HD+/3G 11 Issue 1
3.9 Remote Control Connector/ RS 422 - D9 Socket
This is wired for RS422.
D9 CONTROL
1 0V
6 0V
2 TX-
7 TX+
3 RX+
8 RX-
4 0V
9 0V
5 N/C
3.10 Aux (Dolby Metadata) - D9 Socket
This is wired for RS422.
D9 CONTROL
1 0V
6 0V
2 TX-
7 TX+
3 RX+
8 RX-
4 0V
9 0V
5 N/C
4.0 LS Output
This is a single ended amplifier therefore one side may be connected to ground.
