Meta Data Display This window indicates:
Channel coding (Rate/non PCM/Dolby D/Dolby)
Channel format (e.g. 8x1/2+2+2+2 etc)
Digital peak read out of selected pair.
Dialogue normalisation value where set
N.B. To reset/refresh display press Phase Reverse then Dolby select
switches simultaneously.
2.2 Output Switching and monitoring
A, B, C & D These buttons select the audio from pairs 1/2 (A) through to 7/8
(D)
The buttons toggle. Additive mixing is possible if two or more
buttons are selected together and are fed only to the variable
line outputs.
ALL Enables multi-channel listening on variable outputs. When
selected, multichannel variable outputs are enabled and full
surround can be monitored.
Selecting ALL, holding down and pressing output selection A
or B will toggle between using ABC for discrete 5.1 or BCD for
discrete 5.1.
L Enables the left hand channel to be monitored by both outputs.
R Enables the right hand channel to be monitored by both
outputs.
M A mono signal of the left and right hand channels is applied to
both outputs.
Lt Rt Allows a multi channel signal to be monitored and is a stereo
‘down mix ‘of a Dolby decoded signal. (Mutes multi channel
outputs)
5.1 Enables/Disables 5.1 metadata dynamic range control.
Dim Approximately 16dB of attenuation is switched into the audio
path.
Cut/Mute The front panel button Cut(s) the signal to all Variable O/Ps.
Volume The loudspeaker, headphone and variable O/P’s may be
varied.
