AMU2-8HD+/3G 15 Issue 1
Setup Flash card port. (Factory use only)
Dolby
Dolby Digital or Dolby E decoding from selected
AES input or selected embedded audio.
Note: The Dolby (CAT522) card can be reset by
pressing the phase reverse and the Dolby select
buttons simultaneously.
Display indicates: Channel coding
(rate/non pcm/dolby D/dolby)
Channel format (e.g. 8x1/2+2+2+2 etc)
Digital peak readout of selected pair.
Dial norm value where set
Down converted Output
Return Loss Better than -16.5dB to 1.5GHz
Connector BNC
Note: This is a video monitoring point only.
This connector also gives re clocked
SDV out when SDV is applied to the input.
Re clocked Output
Return Loss < -15dB up to 1.5GHz (3GHz TBA)
Connector BNC
Line Output.
Connector XLR 3 pin Male (variable line out A1 &A2)
Impedance 50Ω
Output Levels Through level control with 12dB gain.
Connector D25
Impedance >20kΩ
Output Levels Fixed (+ and – 1dB) and Variable (12dB gain).
Noise Better than -70 dB (22Hz to 22 KHz)
Headphone Output.
Connector Stereo Jack socket type A
Impedance 50Ω
Output Levels Through level control with 0dB gain.
Loudspeaker Outputs.
Connectors 4mm Binding Posts
Output rating Max 15W /Ch into 4Ω,
