Control Ports
Control ports 1,2,5,6 & 7 – Serial RS422
Pin Numbers
Signal
Pin Numbers
Signal
1
0v/Chassis
6
0v
2
TX
-
7
TX+
3
RX+
8
RX
-
4
0v
9
0v
5
-
Control Port 3 – Serial RS232 (Maintenance port)
Pin
Numbers
Signal
Pin Numbers
Signal
1
-
6
-
2
RX
7
RTS
3
TX
8
CTS
4
DTR
9
-
5
0v
Control Port 4 - Serial RS422 Display Ports
RJ45 DISPLAY CONNECTORS
1
0v
2
0v
3
RX
-
4
TX+
5
TX
-
6
RX+
7
+24v
8
+24v
The Display ports are wired pin to pin, all 8 display ports are paralleled and are addressed as port 4.
UMD displays should be distributed evenly between the eight display drive outputs on the TM2
controller. Cables to the UMDs should be screened CAT5 cable, in order to conform with European
CE requirements it is recommended that CAT5E FTP cable is used
