TSL Tallyman TM1 - Tm2; Internal Power Supply Specification

TallyMan V1.81 on
|
Specification
38
TM2+
Internal Power Supply Specification
This is a MeanWell SP-300 Series unit. In the event of a failure the faulty item should be returned to
TSL for replacement.
The user should not attempt any repairs as this voids the PSU manufacturer’s warranty.
Manufacturer’s Specification Model SP- 300-24
DC Output Voltage
24V
Output Voltage Tolerance
±
1%
Output Rated Current
12.5A
Output Current Range
0
–
12.5A
Ripple and Noise
150mV pk
-
pk
Line Regulation
±
0.2%
Load Regulation
±
0.5%
DC Output Power
300W
Efficiency
86%
DC Voltage
Adjustment
20 ~ 26.4V
Input Voltage Range
88~264VAC 47~63Hz; 124~370VDC
AC Current
4A/115V, 2A/230V
Power Factor
0.9/100~240VAC
Inrush Current
18A/115V 36A/230V
Leakage Current
<
1mA/240VAC
Overload Protection
105~135% Type: Pulsing Hiccup Shutdown
Reset: Auto Recovery
Over Voltage Protection
27.6
-
32.4V
Fan Control Over Temp Protect.
RTH1 or RTH2
>
50

C Fan On,
<
45

C Fan Off
>
70

C Output Shutdown
Temp. Coefficient
±
0.03%/

C (0~50

C)
Setup, Rise, Hold up Time
1.5s, 50ms, 20ms
Vibration
10~500Hz,
2G 10min./1cycle, Period for 60min each axis
Withstand Voltage
I/P
-
O/P:3KVAC I/P
-
FG: 1.5KVAC
Isolation Resistance
I/P
-
O/P, I/P
-
FG, O/P
-
FG:500VDC / 100Mohms
Working Temp. Humidity
-
10

C
-
+50

C (Refer to O/P de
-
rating Curve), 20%
-
90% RH
Storage Temp. Humidity
-
20

C~+85

C, 10%~95% RH
Dimensions
215*115*50mm Case 912
Module weight
1.2Kgs
Safety Standards
UL1950, TUV EN90950 Approved
EMC Standards
CISPR22 (EN55022), IEC1000
-
4
-
2,3,4,5,6,8,11 IEC1000
-
3
-
2 Verification
Notes:
1. All parameters are specified at 230V I/P, rated load, 25C, 70% RH ambient
2. Ripple and noise are measured at 20MHz using a 12” twisted pair terminated with a 0.1uF and 47uF capacitor.
3. Line regulation is measured from low line to high line at rated load.
4. Load regulation is measured for 0% to 100% rated load.
