Introduction
The following document covers installation of the TSL Tallyman controllers TM1, TM2, TM2+ and
TMC-1.
The TSL tally system consists of a number of displays, either discrete modules or Multiviewers / IMD
(In-Picture-Display); controlled by a 19” 1RU remotely located TallyMan Controller.
The TallyMan Controller distributes power and provides the control for the displays. It also carries
user-defined interfaces for routing matrices, vision mixers and output drivers for cue lights and
additional tally control for cameras etc.
All operational set-ups such as the router assignments, mnemonics and tally routing are
programmed with a set-up computer running another version of TallyMan normally connected to
the Ethernet Port on the TallyMan Controller except in the case of the TMC-1 that is configured
locally.
