TSL Tallyman TM1 User Manual

TallyMan V1.81 on
|
Specification
35
Specification
TM1
Internal Power Supply Specification
In the event of a failure the faulty item should be returned to TSL for replacement.
The user should not attempt any repairs as this voids the PSU manufacturer’s three year warranty.
Specifications
Manufacturer’s Specification
Model SUU120
-
180
Input Voltage
90~264 VAC, 47~63 Hz
Input Current
1.0 A @ 230 VAC, 1.7 A @ 115 VAC
Output Voltage
See table below
(plus +/
-
5% adjustment range on O/P 1)
Over Load Protection
110~150% of rated current (auto
-
recovery)
Over Voltage Protection
112~132% of output voltage (crowbar)
Efficiency
70
-
88% (dependent on unit)
Line Regulation
0.5% typically
Load Regulation
+/
-
3% typical on single output units @ 230 VAC input
Hold Up Time
16 ms @ 110 VAC input
Switching Frequency
80 kHz typical
Leakage Current
0.4mA (0.75 mA max.) @ 240 VAC input and full load
Isolation Voltage
I/P
-
O/P: 3 kVAC, I/P
-
FG: 1.5 kVAC
Operating
Temperature
0 °C to +70 °C (derating by 2.5% /

C above 50

C)
Safety Standards
UL60950
-
1, TUV EN60950
-
1
EMC Standard
EN55022 Class B, EN55024, EN61000
-
3
-
2, 3
MTBF
>100 khrs (MIL
-
HDBK
-
217F) @ 25

C
Weight
Approx 0.5 kg
each
Dimensions
127(L) x 81.4(W) x 39.2(H)
Back to Top ^
