TuffStuff AP-250S - Introduction to the Apollo Gym; Product Overview and Specifications; Assembly Preparation and Notes

A
bout the AP-250S_AP-250D
C
ongratulations on your new purchase of the AP-250S_AP-250D.
T
his gym is capable of a variety of different exercises, as well as,
mooth and user-friendly adjustment features. In addition, this gym
as been designed to meet the needs and performance
e
quirements for a suitable home exercise machine. We hope you
a
re completely satisfied with this product and wish you many years
o
f enjoyment.
T
uff Stuff Equipment
T
his Tuffstuff product has been built to precise quality standards
a
nd has been carefully packaged to ensure that damage will not
o
ccur during shipment. The Home Lifetime Warranty and
ignature indicating final inspection has been conducted by our line
o
reman, is an expression of our confidence in the completeness,
h
e materials, and workmanship of this product.
W
arranty
S
EE A COPY OF WARRANTY ON BACK PAGE.
I
n
t
ro
d
uc
ti
on
P
rior to the Assembly of the AP-250S_AP-250D
. We advise you to consult your local Tuff Stuff retailer if you
should have a question or problem regarding the proper
assembly of this Unit.
2
. Consider the complete surface area of the AP-250S_AP-250D.
Use the overhead view on the front page for designing your
layout before assembling. Once the AP-250S_AP-250D has
been fully assembled it will be heavy and difficult to move,
therefore you should assemble the unit in the area where it is to
be used upon completion.
3
. It is recommended that another person assist you with the
assembly this unit.
4
. Neatly organize and identify all parts according to the Parts List
on page 31 and the Exploded View Diagram on fold-out page 32.
Tool Requirements
1.One 9/16” combination wrench
2.One 3/4” combination wrench
3.One 7/8” combination wrench
4.One 7/16” combination wrench
5.One 1/2” combination wrench
6.One ratchet
7.One 9/16” socket
8.One 3/4” socket
9.One rubber mallet
0.One flat head steel hammer
1.External retaining-ring pliers
2.Windex or household glass cleaner
3. One can silicone spray/ teflon spray lubricant
4.Multi-purpose grease
5.Measuring tape
6.Masking tape
7.Utility knife
S
pecifications
Maximum Wt. Capacity - 200 Lbs. Each Weight Stack
Total Machine Weight - 990 Lbs.
Footprint (LWH) - See Front Cover
Assembly Notes
1. Read and follow each step of this Assembly Instruction Manual
i
sequence. Do not skip ahead, as it will result in an improp
e
assembly or in having to disassemble parts later.
2. During the assembly of this unit you will be instructed to lea
v
some Hex Head Cap Screws loosely fastened. Naturally, th
e
will be fully fastened later in the assembly process. This is do
n
to prevent any difficulty with alignment of some parts during th
i
assembly.
About the Icons
The icons displayed in this Owner’s Manual are used to facilitat
e
the correct assembly and safe use of this Product, as-well-as t
o
prevent injury to yourself or anyone else.
Note: Due to continuing product improvements, specifications and designs are subject to chan
g
without notice.
Even though we have prepared this manual with extreme care, neither the publisher nor the auth
o
can accept responsibility for any errors in, or omission from, the information given.
Note provides information necessary to properl
y
complete a procedure or information which wil
make the procedure easier to understand.
Caution indicates a potentially hazardous situa
-
tion, which, if not avoided, may result in minor o
r
moderate injury. It may also be used to aler
t
against unsafe practices.
Fully Fasten provides a instruction to fully fasten
(ex: completely tighten) a hardware assembly.
Loosely Fasten provides a instruction to loosel
y
fasten (ex: hand tighten) a hardware assembl
y
only. This instruction is intended for the alignmen
t
of hardware components during the assembl
y
process.
Hardware Measurement Diagram
SCREW WIDTH
WASHER DIAMETER
NUT DIAMETER
SCREW LENGHT
1
AP-250S_AP-250D Apollo 2-Stack Gym Syste
m
