TuffStuff AP-250S - Top Adjustable Leg Holder Tube Adjustment; Leg Extension Back Pad; Leg Extension Pivot - Arm

A
djustable Leg Extension Pivot–Arm (#25) for quick starting position
p
reference.
Adj
us
t
men
t
F
ea
t
ures
Leg Extension Pivot–Arm (#25) adjustment:
1. Grasp the Pivot-Arm (#25).
2. Pull the Push-Pull Pin 1/2 X 2 3/4 (#137) to releas
e
the Pivot-Arm (#25).
3. Keep the Push-Pull Pin (#137) released and adjus
t
the Pivot-Arm (#25) to the desired position.
4. Release the Push-Pull Pin (#137) and make sure i
fully engages into the selected hole of the Circula
r
Plate w/Axle (#16).
♦
Used for Leg Curl Exercise. ♦ Used for Leg Extension Exercise.
S
ettings A,B,C,D,E,F,G,H,I Settings J,K,L,M,N
Leg Extension Pivot–Arm (#25) Settings
Top Adjustable Leg Holder Tube (#32) adjustment:
1. Grasp the Foam Roll 2 X 5 1/2 X 16 (#51).
2. Pull the Push-Pull Pin 1/4 X 3 1/2 (#136) to release the To
p
Adjustable Leg Holder Tube (#32).
3. Keep the Push-Pull Pin 1/4 X 3 1/2 (#136) released and adjus
the Top Adjustable Leg Holder Tube (#32). to the desire
d
position.
4. Release the Push-Pull Pin (#136) and make sure it full
y
engages into the selected hole of the Top Adjustable Le
g
Holder Tube (#32).
Leg Extension Back Pad (#49) adjustment:
1
.Grasp the Leg Extension Back Pad (#49).
2
. Turn counterclockwise then pull the Turn Pull Pin w/Knob (#138) to
release the Back Pad Adjustable Tube (#47).
3
. Adjust the Back Pad (#49) to the desired position.
4
. Release the Turn Pull Pin w/Knob (#138) and make sure it fully
engages into the selected hole of the Back Pad Adjustable Tube
(#47).
5
. Complete the adjustment by turning the Turn Pull Pin w/Knob
(#138) clockwise.
34
51
29
25
16
137
49
47
12
49
138
47
12
138
51
32
11
136
AP-250S_AP-250D Apollo 2-Stack Gym Syste
m
