12Drive components
Numb
er
Name
Quantity
Remarks
Number
Name
Quantity
Remar
ks
201
Pins
1
213
Screws
2
202
Shaft stop
2
214
Proximity
Switches
1
203
Piston rod
1
215
Nuts
4
204
Screws
2
216
Screws
4
205
Small cover
shell
1
217
Electric
control
1
206
Dust ring
1
218
Press board
1
207
Guide Belt
1
219
Screws
4
208
Seals
1
220
Adjustment
pads
1
209
S Screws
1
221
Screws
4
210
Horn
1
222
Drive Block
1
211
Screws
4
223
Drive
assembly
1
212
Cylinder
barrel
1
20
13Front frame assembly
Numbe
r
Name
Quantit
y
Remarks
Numb
er
Name
Quantity
Remarks
301
Screws
4
310
Bearings
1
302
Switch
1
311
Bearings
1
303
Nuts
4
312
Pins
2
304
Switch
1
313
Screws
4
305
Baffle
1
314
Shaft stop
2
306
Screws
2
315
Support bar
2
307
Support seat
1
316
Screws
6
308
Screws
2
317
Surrounding
frame
2
309
Front Cover
1
21
