Figure 2-5
4.7 Charging jack
The charging port is located on the right side of the vehicle,
as shown in Figure 2-6, and is related to the charger placed in
the vehicle.
The car is an external charger, that is, there is no charger in
the vehicle, charging port for the two-prong socket, charging
with the need for an external charger, the charging port should
be connected with the external charger of the compatible plug.
It can only be charged with the included charger.
Before using the charger, please fully understand the
contents of the instruction manual of the charger.
Please observe these rules.
The charging area must be well ventilated.
8
Figure 2-6
4.8 Vehicle driving steering
The direction of vehicle travel is controlled by the handle.
See Figure 2-7 shows
a Turn the handle in a flat direction to the left and the
vehicle turns left.
b Turn the handle in a flat direction to the right and the
vehicle turns right.
Figure 2-7
9
