PARTS LIST
1 BASE FRAME 1
2 FRONT FOOT 1
3 REAR FOOT 1
4 REAR FOOT COVER 1
5 FRONT FOOT COVER 1
6 HEIGHT ADJUSTMENT SCREW 5
7 DIN 7985 A M5*12MM SCREW 2
8 DIN 7981 C M5*20MM G SCREW 20
9 ISO 7380 M8*58MM SCREW (*2 PCS) 2
10 127 B M8 SPRING WASHER 14
11 DIN 125 A M8 1.2 16MM WASHER (8PCS) 12
12 TRANSPORT WHEEL 2
13 TRANSPORT WHEEL BUSHING 4
14 ISO 7380 M8*63MM SCREW 2
15 PLASTIC SPACER FOR PCB 2
16 DIN 985 NYLOC NUT M8 2
17 UPRIGHT TUBE 1
18 UPPER U.I. CABLE 1
19 MOVING HANDLE BAR, RH 1
20 MOVING HANDLE BAR, LH 1
21 MOVING HANDLE BAR BUSHING 6
22 USER INTERFACE (U.I.) 1
23 ISO 7380 M8*15MM SCREW (*4 PCS) 4
24 M8*2*38MM WASHER (*2PCS) 2
25 AXLE FOR MOVING HANDLE BARS 1
26 6002ZZ BEARING 4
27 15,5*20*3T WASHER 2
28 PEDAL TUBE, RIGHT 1
29 PEDAL TUBE, LEFT 1
30 PEDAL, LEFT 1
31 PEDAL, RIGHT 1
32 DIN 912 M6*53MM SCREW 1
33 MOVING HANDLEBAR END CAP 2
34 MOVING HANDLEBAR FOAM 2
35 PEDAL SHAFT 2
36 PEDAL FRONT END CAP 2
37 ISO 7380 M8*25MM SCREW (*2 PCS) 2
38 PEDAL REAR END CAP 2
39 ISO 7380 M8*20MM SCREW (*4 PCS) 4
40 M8*1,5*22MMWASHER (*2 PCS) 2
41 DIN 471 RETAINING RING 40*1.75MM 2
42 PEDAL TUBE BUSHING 2
43 SELF-ALIGN-BALL-BEARING 2
44 MAIN COVER (R) 1
45 MAIN COVER(L) 1
46 SCREW COVER 2
47 DIN 7981 C M4*15MM SCREW 4
48 TURNING PLATE CAP 2
49 DIN 7991 M8*58MM SCREW (*2 PCS) 2
52 DIN 7985 A M6*15MM SCREW (*2 PCS) 2
53 LOWER U.I. CABLE 1
54 DIN 7985 A M5*10MM SCREW (*1 PC) 1
55 FRONT SLEEVE 1
56 HEAD TUBE ADAPTOR 1
57 BASE FOR USER INTERFACE 1
58 U.I. MOUNTING CLAMP 1
59 OVAL END CAP 1
60 ISO 7380 M8*42MM SCREW (*2 PCS) 2
61 DIN 137 A M8 CURVE WASHER (*2 PCS) 2
62 FIXED HANDLE BAR BRACKET 1
63 FIX HANDLEBAR 1
64 FIXED HANDLEBAR FOAM 2
65 DIN 7981 C M3*15MM SCREW 2
66 FIX HANDLEBAR END CAP 2
67 HAND PULSE (H.P.) SENSOR SET 2
68 HAND PULSE WIRE 2
69 DIN 7985 A M5*12MM SCREW 4
70 DIN 985 NYLOC NUT M6 1
71 DIN 7985 A M6*10MM SCREW 1
72 DIN 127 B M6*2T SPRING WASHER (2PCS) 2
73 DIN 127 B M5 SPRING WASHER (*6 PCS) 6
74 DIN 126 M6*1.2 WASHER 1
75 SENSOR BRACKET 1
76 ISO 7380 M6*14MM ALLEN SCREW 4
77 DIN 126 M6*1.2 WASHER 4
78 ADAPTOR 1
79 3/8” TURNING PLATE AXLE NUT 2
80 TURNING PLATE 2
81 BELT 1
82 CROSS FRAME 2
83 AXLE FOR PULLEY 1
84 PULLEY 1
85 MAGNET 9
86 6203 ZZ BEARING 2
87 PLASTIC SPACER 2
88 DIN 933 M6*18MM BOLT 4
89 DIN 985 NYLOC NUT M6 4
90 DIN 471 RETAINING RING 17*1MM 2
91 DC WIRE 1
92 SENSOR WIRE 1
93 DIN 7981 C M6*12 MM SCREW 1
94 EXTENSION WIRE 1
95 EMS SYSTEM 1
96 DIN 127 B M6 SPRING WASHER 4
97 CONTROL BOARD 1
98 SQUARE CAP FOR 30 X 70MM TUBE 1
99 DIN 125 A M5*1.5MM WASHER (*6 PCS) 6
100 DIN 85 A M5*42 MM SCREW (*4 PCS) 4
- HARDWARE KIT 1
- OWNER’S MANUAL 1
- WARRANTY BOOKLET 1
- LABEL SET 1
