Tunturi CENTURI E100 - Page 97

97
Centuri E100 Bike
1 Console E100(BAI+BT) Metric settings 1
2 Screw M5x10 3
3 Console bracket black 1
4 Console bracket seat Compl Assy� Gen� B Parts: 2 ~ 10 1
4 Console bracket seat Gen B Black PA 1
5 Bushing Bushing ♂6.0*♂9.8*48.5L 1
6 Screw M6xP1�0x60L 1
7 Flat washer Ø6xØ13x1t 2
8 Nylon nut M6 1
9 Console locking knob Black ABS 1
10 Fixed washer Black nylon 1
11 Handlebar Compl Assy� Parts: 11 ~ 16 1
11 Handlebar Black 1
12 Foam grip Foam grip 720x♂23x3.0mm 2
13 Hand pulse sensor Set 2
14 Hand pulse sensor wire 350mm _ 2P Set� 1
15 Screw M4x20 2
16 Handlebar End cap Ø1" 2
17 Handlebar tightener Aluminum 1
18 Handlebar post Compl� Assy� Gen�B RAL9004 black 1
18 Handlebar post Gen� B RAL9004 black 1
19 Console cable, upper 1150mm _ 12P 1
20 Screw M5xP0�8x20L 2
21 Bottle holder Black, nylon 1
22 Main frame RAL9004 black 1
23 Nyloc screw M8x12L 3
24 Driving pulley Ø240-6P Ø17 1
25 Axle for pulley Ø17x175L 1
26 Bushing Ø22xØ17x7�5mmL 1
27 Screw Screw M10x45L 2
28 Hexagaonal screw M8xP1�0x20L 2
29 Seat post knob M16xP1�5x25L Black 1
30 Crank (LH) 9/16"x 6.5" 1
31 Crank (RH) 9/16" x 6.5" 1
32 Nut M17 1
33 Flate washer Ø17�5xØ25x0�3t 2
35 Seat post sleeve Black PP 1
36 Bearing 6203 (RS) 2
37 Sensor holder Black 1
38 Flat washer Ø5xØ10x1t 2
39 Screw M4xP1�5x16L 2
40 Sensor wire 400mm _ 2P 1
41 DC wire 400mm _ 3P 1
42 Drive belt PJ1092 - 430J - 6P 1
NR Description Specs Qty
B.O.M.
