98
Centuri E100 Bike
NR Description Specs Qty
B.O.M.
43 Side cover E100, Left (PMS 425 grey to paint
black color)
PMS 425 grey to paint black color 1
44 Side cover E100, Right (PMS 425 grey to paint
black color)
PMS 425 grey to paint black color 1
45 Crank cap RAL9004 black (glossy) 2
46 Top cover RAL9004 black (glossy) 1
47 Seat post cover RAL9004 black (glossy) 1
48 Cover of bottom tube RAL9004 black ABS 1
49 Handlebar post cover RAL9004 black ABS 1
50 Ring for handlebar post RAL9004 black (glossy) 1
51 Shaft of chain cover White 2
52 Screw Screw M4x12L 3
53 Screw M5x16L 5
54 Pedal straps for F20 (2017) 1
54L Pedal, Left 9/16" 1
54R Pedal, Right 9/16" comes with 54L 1
55 Switching adaptor Output DC 9V/1A_Input 110- 230V A_C Plug 1
Switching adaptor Output DC 9V/1A_Input 110- 230V A_A Plug 1
56 Fixed tube of bracket RAL9004 black 2
57 Seat post RAL9004 black 1
58 Horizontal sliding tube RAL9004 black 1
59 Fixed screw 7/16"-14 1
60 Seat sliding knob 1
61 Flat washer Ø12�5xØ20x2t 1
62 End cap Black (PP) 2
63 Seat (SB-27) 1
64 Flywheel compl. (incl. 65~76) Ø250x32W 6�0 kg (freewheel CCW) 1
65 Nut 3/8"-26x4.5t 5
66 Axle for flywheel 3/8"-26x122L 1
67 One-way bearing set KR-6003 1
68 Pulley for flywheel J8xØ30 1
69 Bearing 6900 (RS) 1
70 Bearing 6003 (RS) 1
71 Bearing 6203 (RS) 1
72 Bearing 6300 (RS) 1
73 Flat washer Ø30xØ34x1t 1
74 Star washer Ø10xØ17x1t 2
75 Plastic sleeve Ø10xØ14x6mmL 1
76 Bushing Ø10xØ14x3mmL 1
77 Servomotor set F40, E50 EB-G gear box _ CABLE 950L 1
78 Magnetic brake Compl Assy� Parts: 78 ~ 81 1
78 Magnetic brake set 10-magnet 1
79 Flat washer Ø6xØ13x1t 2
80 Hexagaon Screw M6xP1�0x12L 2
