TurboChef 30 - Page 49

39
Reference
48-3/4 ˝
(1238 mm)
23-7/8 ˝ (606 mm)
25˝
(635 mm)
the wall
Single Wall / Double Wall Top Oven
Double Wall Bottom Oven
23-7/8
˝
(606 mm)
19 -1/2˝
(499 mm)
4 -1/4˝ (109 mm)
17 -1/2˝
(448 mm)
28˝ (717 mm)
30˝ (762 mm)
50-1/4˝
(1276 mm)
26-1/2˝
(673 mm)
30˝ (762 mm)
3/4˝ (19 mm)
3/4˝ (19 mm)
23 -7/8˝ (606 mm)
3/4˝ (19 mm)
3/4˝ (19 mm)
