13
240064-1
13 • INSTALLATION DIAGRAMS
500mm
20inch
50mm / 1,9inch
400mm
15,7inch
400mm
15,7inch
DISTANCES TO BE ADHERED TO
The appliance cannot be recessed.
One of the two sides must be
exposed.
Minimum distance from wall: 50mm /
1.9 inches
AVOID POSITIONING HEAT-
RADIATING APPLIANCES ON
EITHER SIDE OF THE OVEN
ATTENTION: if the temperature
on the sides of the appliance
is excessively high, as a safety
precaution the oven will switch off.
Minimum distance from heat sources
on both sides: 400mm / 15.7 inches.
