Tuson TPMS - Page 52

52
8.5.3 Move the receiver close to the wheel of the vehicle/trailer wheel to be paired
<IMPORTANT 9>
You do NOT have to pair the sensors that were included in the Tuson TPMS Retrofit Kit if you followed
Section 4. For example, if you purchased a 6-wheel TPMS Retrofit Kit and 2 additional sensors to monitor
8-wheels total on CAR 1, you will need to pair wheel location 7 and 8 ONLY since 1-6 will already be paired
to the receiver.
8.5.4 If the Setting Mode Menu timed out and returned to Driving Mode Menu, then hold for 3
seconds and press until you reach the Tire Sensor ID Pairing setting screen. (Note: The
last selected vehicle selection will be the one that you are pairing. If it is not the vehicle selection
that you would like to perform the Tire Sensor ID Pairing, then you will need to perform Setting 8.1
again.)
8.5.5 The Tire Sensor ID Pairing screen will show “--1” at the left-front tire sensor by default.
