8.6 Setting the Tire Position on the Receiver
The Setting the Tire Position on the Receiver TPMS parameter setting is available to the user when
performing a tire rotation or when sensors are incorrectly paired to the receiver and need to be swapped.
Once you have determined the tire locations that you would like to swap, follow the instructions below:
8.6.1 Press and hold for 3 seconds to enter the Settings Mode Menu. Follow Setting 8.1 to select
the vehicle selection that you need to perform the tire position swap, then press twice to go to
the Setting the Tire Position on the Receiver screen.
8.6.2 The Setting the Tire Position on the Receiver screen shows the numbered tire positions for each
tire sensor on the receiver for the vehicle selection as pictured below.
