fillrite.com | tuthill.com
14
| H-SERIES FUEL TRANSFER PUMPS
INSTALLATION AND OPERATION MANUAL
Specications and Models
Description FR1200 FR4200 SD1200 FR4400 FR2400 FR600 SD600
Motor
Voltage, Supply (DC/AC) 12V DC 24V DC 115V AC / 60HZ
Power (HP) 1/4
TH
1/6
TH
Amps (Full Load) 26 28 26 18 15 2.5
Amps (Rated) 20 19 20 13 10 2.0
RPM 2600 RPM 2000 RPM
Power Cord
*
Length 18'
15'
18'
Not Included
AWG 12
Duty Cycle 30 Minutes (on), then 30 Minutes (off)
Thermal Protection (motor) Yes
Required Circuit Protection 30 AMP 20 AMP 15 AMP
Description FR1200 FR4200 SD1200 FR4400 FR2400 FR600 SD600
Pump
Maximum GPM 15 20 13 20 15 13
Bypass Pressure 16 PSI
Minimum Dry Vac 5 IN-HG
At Sea Level
70° F (21.1° C)
Suction Lift
8' Maximum
Outlet Head
37' Maximum
Inlet 1" NPT
Outlet 3/4" NPT 1" NPT 3/4" NPT 1" NPT 3/4" NPT
Mount 2" NPT Inlet Bung
Warranty Limited Lifetime Warranty
†
1 Year Limited Lifetime Warranty
†
1 Year
Product Parts Product Materials
Pump Housing Cast Iron
Rotor Powdered Iron
Vane Sintered Bronze
Strainer Mesh Stainless Steel
Wetted Components Buna-N, Fluorocarbon, Ceramic, Cork, Thermoset, Steel, Stainless Steel
†
Warranty details can be found at fillrite.com
*Power cord not included in pump only models
A series of fuel transfer pumps with UL/cUL certifications that are compatible with gasoline, diesel fuel, blended fuels such as biodiesel up to 20%, gasoline
with up to 15% ethanol, mineral spirits, and kerosene.
