48
PARTS LIST FOR MODEL 5500C SERIES
ITEM
NO. DESCRIPTION 90/91 92/93
1 ROTOR 2 2
3 HOUSING 1 1
4 END PLATE 2 2
6 DRIVE END COVER 1 1
7 FREE END COVER 1 1
8 TIMING GEAR SET 1 1
9 BEARING, DRIVE END 2 2
10 BEARING, FREE END 2 2
13 LIP SEAL 1 1
14 BEARING RETAINER 4 4
20 OIL SLINGER 0 / 1 0 / 1
21 OIL SLINGER ASSEMBLY 1 1
22 DOWEL PINS 6 6
23 DRIVE SHAFT KEY 1 1
24 GEAR KEY 2 2
25 ROTOR SHAFT WASHER 1 1
26 CAP SCREW 28 28
29 FLAT SOCKET SCREW 1 1
30 SOCKET SCREW 6 6
31 MAGNETIC PIPE PLUG 2 2
35 GEAR LOCKNUT 2 2
38 PORT FITTING 1 / 2 1 / 2
40 HEX HEAD CAP SCREW 28 28
45 DRIVE SHAFT 1 1
48 PORT FITTING (5507) 1 / 0 1 / 0
51 LABYRINTH SEAL 4 —
54 MECHANICAL SEAL 4 —
57 SPACER 1 1
61 LOCKPLATE 6 6
62 CAP SCREW 12 12
65 LOCKPLATE 2 2
66 SCREW 4 4
68 OIL SLINGER PIN 1 1
69 FLAT SOCKET SCREW 1 1
ITEM
NO. DESCRIPTION 90/91 92/93
70 SIGHT GLASS 0 / 1 0 / 1
76 MECHANICAL SEAL 1 1
79 OIL RETAINER — 4
80 WASHER 0 / 1 0 / 1
85 PIPE PLUG 6 6
91 SEAL ADAPTER HOUSING 1 1
92 O-RING 1 1
93 SCREW 4 4
94 COOLING COILS 2 —
95 O-RING 4 —
96 O-RING 4 —
97 MANIFOLD SCREW 4 —
98 PIPE PLUG 6 6
123 BEARING SPACER 2 2
136 LOCKWASHER 0 / 1 0 / 1
166 CONNECTOR 2 —
174 PIPE PLUG 2 2
180 ELBOW 2 —
181 HOSE 1 —
238 SLINGER — 4
241 SOCKET SCREW 12 12
242 SIGHT GLASS FRAME 2 2
243 SIGHT GLASS WINDOW 2 2
244 WINDOW GASKET 2 2
245 FRAME GASKET 2 2
303 COVER PLATE 2 2
309 CAP SCREW 8 8
NOTES:
• QUANTITIES SHOWN ARE MAXIMUM VALUES;
QUANTITIES MAY VARY BETWEEN BLOWER
PARTS KITS ARE AVAILABLE, AS FOLLOWS:
90/91 — P/N 55272
92/93 — P/N 55399
