PARTS LIST FOR MODEL 7000C SERIES
ITEM
NO. DESCRIPTION 90/91
1 ROTOR 2
3 HOUSING 1
4 END PLATE 2
6 DRIVE END COVER 1
7 FREE END COVER 1
8 TIMING GEAR SET 1
9 BEARING, DRIVE END 2
10 BEARING, FREE END 2
13 LIP SEAL 1
14 RETAINER 2
15 RETAINER 2
20 OIL SLINGER 1
22 DOWEL PIN 8
23 DRIVE SHAFT KEY 1
24 GEAR KEY 2
25 ROTOR SHAFT WASHER 4
26 CAP SCREW 36
29 BOLT 4
30 CAP SCREW 16
31 MAGNETIC PIPE PLUG 2
45 DRIVE SHAFT 1
51 LABYRINTH SEAL 4
54 MECHANICAL SEAL 5
49 LOCKING TAB 4
66 CAP SCREW 4
68 ROLL PIN 4
70 SIGHT GLASS 2
74 SEALING RING 4
ITEM
NO. DESCRIPTION 90/91
75 O-RING 5
80 WASHER 4
85 PIPE PLUG 14
89 LOCKING RING 1
90 SET SCREW 3
91 LIP SEAL 1
92 O-RING 1
93 CAP SCREW 4
94 COOLING COILS 2
95 O-RING 4
96 O-RING 4
97 BUSHING 4
98 PIPE PLUG 4
174 PIPE PLUG 4
195 LIFTING LUG 2
196 CAP SCREW 2
199 O-RING 2
300 ROLL PIN 5
304 FOOT 2
307 CAP SCREW 4
339 STRAIGHT PLUG 6
395 OIL SLINGER 2
499 BUSHING 1
NOTES:
• QUANTITIES SHOWN ARE MAXIMUM VALUES;
QUANTITIES MAY VARY BETWEEN BLOWER
PARTS KITS ARE AVAILABLE, AS FOLLOWS:
90/91 — P/N 77165
