Tuttnauer EZ9 - Specifications

10
2.9 Specifications
Overall Dimensions
EZ9 EZ10, EZ10K
Model
Dimensions
mm in mm in
A 510 20.0 510 20.0
B 365 14.4 365 14.4
Overall Dimensions
C 540 21.5 545 21.5
D 910 35.8 910 35.8
Maximum
Dimensions (door
open)
E 630 24.8 655 25.8
F 299 11.8 299 11.8
F1 422 16.6 422 16.6
G 50 2.0 50 2.0
Distance Between
Supporting Legs
H 400 15.8 400 15.8
Reservoir Volume 3 lit. 0.8 gal. 3 lit. 0.8 gal.
Minimum Water Volume in
Reservoir
0.8 lit. 0.21 gal. 0.8 lit. 0.21 gal.
Max. Allowable Working
Pressure (MAWP)
2.76 bar (40 psi)
Load No. Counter Counting from 0 to 250 and nullifies.
