Tuttnauer EZ9 - KEYBOARD (Keys and Display)

13
FRONT VIEW
No. Description No. Description
1 Reservoir water drain valve 9 Air relief valve
2 Ring for drain valve 10 Panel base
3 Door closing device 11 Front panel key board
4 Door switch (under door) 12 Printer
5 Autoclave cover 13 Main switch
6 Water reservoir cover 14 RS232 port cover
7 Water reservoir – assembly 15 Completion to panel
8 Safety valve
