The re will be a visual and audible release of steam
from the rear of the Steam Duct.
Open
Close
3.3 Closing
Always place the lid on the autoclave with the Depressur-
ization Valve (A) open. Align the two black triangles on the
cover and body as shown in (F3) and turn in a clockwise
direction (F1) ensuring the lid is completely closed (F2).
Close the Depressurization Valve (A) so it is aligned with
the top handle on the lid. Never leave the autoclave in the
position as shown in (F1).
3.4 Power connection
Attach the cable supplied to the rear of the unit and
plug into a GROUNDED main electrical socket of the
CORRECT voltage. Lights: (L1) illuminates GREEN. If
this ashes continuously, then there is an error, and you
should contact Tuttnauer for further assistance.
