TVLogic F-5A User Manual

FHD Viewnder Monitor 8
3. Controls & Functions
TOP REAR
• [MENU/EXIT/SOURCE] Button
- Used to activate the OSD menu.
- When the OSD menu is activated, press this
button to exit from the menu.
- Press the button for more than 2 seconds to
activate Input Select menu. (SDI, HDMI)
- Use the [ENCODER] Knob to change the Input
Signal.
• [UP/DOWN/ENTER] Knob
- Used to move within the menu when OSD
menu is activated, and is also used to decrease
or increase the value of the selected feature.
- Press the knob to select the main menu and
the sub menus.
• [F1]~[F3] Button
- Press the button for less than 2 seconds to
activate the function.
- Press the button for more than 2 seconds to
activate Function Select menu. (Scan, Aspect,
H/V delay, etc.)
- Press the button for more than 2 seconds to
indicate previously selected function. Use the
Knob to change the function.
• [USB]
- This terminal is used to upgrade the rmware
or color calibration made by TVLogic.
• [POWER] Switch
- Used to turn the power on and o.
