Name & Function of Each Part
- Used to change the Phase value. Press [PHASE] button and use [UP]/[DOWN] button to control.
#Phase is not available in DVI Analog & PAL mode.
[WAVEFORM]/[VECTOR SCOPE] Button/Lamp (Refer to page 19-20)
- Pressing the button activate features in the order of: [O]-[Wave form]-[Vector Scope]-[Wave
Form Wide]-[Wave Form YCbCr]-[Wave & Vector]- [Vector_YCbCr]-[O]
- [Wave Form YCbCr] : Displays each waveform for elements of the luminance and Cb/Cr of the
- [Wave & Vector] : Displays waveform and vector scope simultaneously.
- [Vector YCbCr] : Displays Vector scope and Y/Cb/Cr waveform simultaneously.
* See section “Other Functions [6]Wave Form function and [7]Line Select” for more information.
- Used to activate the main OSD Menu.
- Used to move within the menus during OSD menu activation and is also used to increase the
value of selected feature.
- In Pixel to Pixel mode, press the button to rotate the display clockwise.
- Used to move within the menus during OSD menu activation and is also used to decrease the
value of the selected feature.
- in Pixel to Pixel mode, press the button to rotate the displays counterclockwise.
- Used to conrm a chosen value.
- Power On/O button. If the signal is normal, LED lights in Green. If the signal is unsupported or
disconnected, LED ashes in Yellow.
- Tally lamp that can be toggled in green or red using the REMOTE(RJ-45) port or RS-422 serial
- Used to adjust the picture sharpness. The value is selectable between -12 ~ 12.
#Aperture is not available in DVI Analog or Graphic mode.
- Used to adjust the degree of brightness.
- The value is selectable between -25 ~ 25 (LVM-071W), -128 ~ 127 (LVM-091W).
- Used to adjust the saturation of the image.
- The value is selectable between -25 ~ 25 (LVM-071W), -128 ~ 127 (LVM-091W).
# This feature is not available in DVI Graphic mode and DVI Analog.
