Information
Input VIDEO connection method
GGGGG
GGGGG
Warning!!
Before using this unit make certain to connect the power supply before connecting a
signal to any of the inputs. The unit may not function properly if a signal is connected
before the power supply is connected. As an example: the unit will not function properly
when using an RCA-to-BNC (BNC-to-RCA) connection if the signal is connected to the
input before the unit is connected to the power supply.
!
Connector Composite Component S-Video
1CVBS1YG Y
2
CVBS2 Pb B No Con.
3CVBS3PrRC
LVM-170W (G) / 230W / 240W
