TVLogic LVM-170W (G) User Manual

75
<REAR>
· REMOTE (RJ-45)
Connection for remote control of monitor.
· DVI-IN / FACTORY PGM
Input connection for DVI mode and input connector for FACTORY PGM allowing for
firmware updates.
· CVBS1/Y/G/S-Y (BNC)
Signal input terminal used for COMPOSITE1, S-VIDEO Y, COMPONENT Y, RGB G signals.
· CVSBS2/Pb/B (BNC)
Signal input terminal used for COMPOSITE2, RGB B, COMPONENT Pb signals.
· CVSBS3/Pr/R/S-C (BNC)
Signal input terminal used for COMPOSITE3, S-VIDEO C, COMPONENT Pr, RGB R signals.
· SDI-IN A (BNC)
SDI signal input terminal that provides A signal.
· SDI-OUT A (BNC)
SDI signal output terminal used for SDI A output.
· SDI-IN B (BNC)
SDI signal input terminal that provides B signal.
· SDI-OUT B (BNC)
SDI signal output terminal used for SDI B output.
· ~ AC IN
Used to supply AC power; 100V~240V input range.
· DC 24V IN
Used to supply DC power; 24V
LVM-170W (G) / 230W / 240W
