74
· MENU
Used when OSD menu is activated.
· DOWN/BRIGHT
Used to navigate menu during OSD menu activation. It may also be used to control
the BRIGHT value when the OSD menu is not active.
· UP/CONTRAST
Used to navigate the menu during OSD menu activation. It may also be used to
control the CONTRAST value when the OSD menu is not active.
· ENTER
Used to confirm a chosen value (or mode) during OSD menu activation or inactivation.
· STANDBY
Indicates power supply connection and current setting. The lamp is RED when unit is
connected to power supply and in standby mode and GREEN during system operation.
In case of sudden loss of power unit retains last setting.
· TALLY
LED indicating monitors current status
LVM-170W (G) / 230W / 240W
