VEHICLE FRONT SIDE
1. Rear view mirror R
2. Headlamp assembly
3. Turn signal lamp front R
4. Bend lamp assembly R
5. Rear view mirror R
6. Turn signal lamp front L
7. Bend lamp assembly L
VEHICLE REAR SIDE
1. Tail / brake lamp
2. Turn signal lamp rear L
3. License plate lamp
4. Turn signal lamp rear R
5. Reflex reflector
