VEHICLE TOP SIDE
1. Instrument cluster 11. Lid charging port
2. Master cylinder R 12. Switch turn signal lamp
3. Park assist switch 13. Horn switch
4. Hazard switch 14. Navigation switches
5. Front brake lever 15. Guard lever L
6. Guard lever R 16. Rear brake lever
7. Throttle grip 17. Headlamp beam control / Pass-by Switch
8. Ride / kill switch 18. Cruise control switch
9. Mode switch 19. Seat unlock switch
10. Power ON switch 20. Master cylinder L
