twin busch TW 242 E - Attachment (Pack List)

TWIN BUSCH GmbH
Technical changes for purposes of a technical advancement as well as deviation in colour, errors and printing mistakes are reserved.
page 19 of 45
Attachment (Pack List)
S/N
Material #
Name
Drawing#
Property
Qty
1
Power side post assembly
FL-8224E-A1
Assembly
1
2
Post assembly
FL-8224E-A2
Assembly
1
3
Carriage assembly
FL-8224E-A3
Assembly
2
4
Power unit
Assembly
1
5
Oil cylinder
FL-8224-A4-B3
Assembly
1
6
Drive oil cylinder
FL-8224-A4-B2
Assembly
1
7
Electrical system
Assembly
1
8
Control box
1
9
Wire package
1
10
Steel cable L=8820mm
FL-8224E-A6
Assembly
2
11
Long arm
FL-8224-A7
Assembly
2
12
Short arm
TW-235E-A8
Assembly
2
13
14
Base cover plate
FL-8224-A10
Powder-coating
1
Carton(includes the following ）
17
18
Arm shaft
FL-8224 -A12
Zinc-plating
4
19
20
Short feet-protection fender
FL-8224 –A18-B4
Powder-coating
2
21
Long feet-protection fender
FL-8224–A7-B4
Powder-coating
2
22
Lifting tray assembly
FL-8224 –A7-B3
Assembly
4
23
Rubber oil hose L=500mm
Assembly
1
24
Rubber oil hose L=2900mm
8224E-B4-B2
Assembly
1
25
Safety locking plate
FL-8224E –A1-B2
Zinc-plating
26
27
Positioning block
FL-8224E –A1-B3
Zinc-plating
28
Hose & wire cover
FL-8224E –A1-B8
Powder-coating
6
29
Chain protection cloth
FL-8224 -A11
Assembly
2
30
Rod of chain protection cloth
FL-8224 -A13
Zinc-plating
4
31
Rubber protection pad
FL-8224 –A3-B7
Rubber
2
32
Nylon washer
FL-8224 -A17
Rubber
10
33
34
Hex head full swivel nut
M10*35
Standard
4
35
Hex socket cylinder head screw
M8*12
Standard
8
36
Cross cap screw
M6*10
Standard
28
37
Cross cap screw
M6*30
Standard
12
38
Cross cap screw
M6*16
Standard
4
39
Cross sunken head screw
M8*16
Standard
4
40
Class C flat washer
M6
Standard
8
41
Class C flat washer
M10
Standard
4
42
Spring washer
M10
Standard
4
Hex nut
M6
Standard
8
Hex nut
M10
Standard
4
Type B circlip
38
Standard
4
Expansion bolt
M18*180
Standard
10
