12
Connector type D-Sub 15-pin
Graphic
Chipset Aspeed AST2300
USB
(11) USB 2.0 ports (4 at rear, 6 via cable, 1 type A
onboard)
COM
(1) DB-9 COM Connector (at rear, COM1) + (1)
Header (COM2)
SAS (2) Mini-SAS (4-in-1) connectors
VGA (1) D-Sub 15-pin VGA port
RJ-45 (3) GbE ports
Power
SSI 24-pin + 8-pin + 8-pin + 4-pin power
connectors
Front Panel (1) 2x12-pin SSI front panel header
Input /Output
SATA (4) SATA-II and (2) SATA-III connectors
Voltage
Monitors voltage for CPU, memory, chipset &
power supply
Fan Total (6) 4-pin headers
System
Monitoring
Temperature
Monitors temperature for CPU & system
environment
Onboard Chipset Onboard Aspeed AST2300
AST2300 IPMI
Feature
IPMI 2.0 compliant baseboard management
controller (BMC) / Supports storage over IP and
remote platform-flash / USB 2.0 virtual hub
Server
Management
AST2300 iKVM
Feature
24-bit high quality video compression / 10/100
Mb/s MAC interface
Brand / ROM size AMI / 8MB
BIOS
Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3
/PXE boot / ACPI 2.0 power management /Power
on mode after power recovery / User-configurable
H/W monitoring / Auto-configurable of hard disk
types
Form Factor SSI EEB
Physical
Dimension
Board Dimension 12"x13" (305x330mm)
Operating System OS supported list Please visit out Web site for the latest update.
FCC (DoC) Class A
Regulation
CE (DoC) Yes
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp.
- 40° C ~ 70° C (-40° F ~ 158° F)
Operating
Environment
In/Non-operating
Humidity
90%, non-condensing at 35° C
RoHS RoHS 6/6 Compliant Yes
Motherboard (1) S7055 Motherboard
Manual (1) Quick Installation Guide
Package Contains
Installation CD (1) TYAN installation CD
