Chapter 1: Instruction
1.1 Congratulations
You have purchased the powerful TYAN
®
S7055 motherboard, based on the
Intel
®
Patsburg (C602) chipset. The S7055 is designed to support dual Intel
®
Xeon E5-2600 Series processors, and up to 128GB RDIMM and 64GB UDIMM
DDR3 memory. Leveraging advanced technology from Intel
®
, the S7055 is
capable of offering scalable 32 and 64-bit computing, high-bandwidth memory
design, and lightning-fast PCI-E bus implementation.
The S7055 not only empowers you in today’s demanding IT environment but also
offers a smooth path for future application upgradeability. All of these rich feature
sets provide the S7055 with the power and flexibility to meet demanding
requirements for today’s IT environments.
Remember to visit the TYAN
®
website at http://www.tyan.com. There you can find
all the information on all TYAN
®
products as well as all the supporting
documentation, FAQs, Drivers and BIOS upgrades.
1.2 Hardware Specifications
TYAN S7055 (S7055AGM3NR)
Supported CPU
Series
Intel Xeon Processor E5-2600 Series
Socket Type / Q'ty (2) LGA2011
Thermal Design
Power (TDP)
wattage
150W
Processor
System Bus
Up to 8.0/ 7.2/ 6.4 GT/s with Intel QuickPath
Interconnect (QPI) support
Chipset PCH Intel C602
Supported DIMM
Qty
(4)+(4) DIMM slots
DIMM Type / Speed
DDR3/DDR3L 800 / 1066 / 1333 / 1600 RDIMM,
1066 / 1333 / 1600 UDIMM, 1066 / 1333 LRDIMM/
Support DDR3 Unbuffered and Register ECC
Capacity
Up to 256GB RDIMM / 64GB UDIMM / 256GB
LRDIMM
Memory channel 4 Channels per CPU
Memory
Memory voltage 1.5V or 1.35V
PCI-E
(4) PCI-E x16 Gen3 slots (x16 link, slot #7, #5, #3,
#1) / (1) PCI-E x8 Gen2 slot (x4 link, slot #4)
Expansion Slots
PCI (1) PCI 32-bit slot (slot #2)
Recommended 4U Barebone FT48-B7055
