6
Barebone /
Chassis
Port Q'ty (3) GbE ports
LAN
Controller Intel 82574L / Intel I350-BT2
Connector (10) SATA; (2) 6G + (8) 3G
Controller Intel C602
Speed
(2) 6.0 Gb/s (blue color), (4) 3.0 Gb/s (black color)
+ (4) 3.0 Gb/s (mini-SAS connector)
Storage SATA
RAID RAID 0/1/10/5 (Intel RST)
Connector type D-Sub 15-pin
Graphic
Chipset Aspeed AST2300
Chipset Realtek ALC262
Audio
Feature HDA 2.0 spec. complaint
USB
(11) USB 2.0 ports (4 at rear, 6 via cable, 1 type A
onboard)
COM
(1) DB-9 COM Connector (at rear, COM1) + (1)
Header (COM2)
VGA (1) D-Sub 15-pin VGA port
Audio LINE_IN, LINE_OUT, MIC_IN connectors
RJ-45 (3) GbE ports
Power
SSI 24-pin + 8-pin + 8-pin + 4-pin power
connectors
Front Panel (1) 2x12-pin SSI front panel header
Input /Output
SATA (4) SATA-II and (2) SATA-III connectors
Voltage
Monitors voltage for CPU, memory, chipset &
power supply
Fan Total (6) 4-pin headers
System
Monitoring
Temperature
Monitors temperature for CPU & system
environment
Onboard Chipset Onboard Aspeed AST2300
AST2300 IPMI
Feature
IPMI 2.0 compliant baseboard management
controller (BMC) / Supports storage over IP and
remote platform-flash / USB 2.0 virtual hub
Server
Management
AST2300 iKVM
Feature
24-bit high quality video compression / 10/100
Mb/s MAC interface
Brand / ROM size AMI / 8MB
BIOS
Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3
/PXE boot / ACPI 2.0 power management /Power
on mode after power recovery / User-configurable
H/W monitoring / Auto-configurable of hard disk
types
Form Factor SSI EEB
Physical
Dimension
Board Dimension 12"x13" (305x330mm)
Operating System OS supported list Please visit out Web site for the latest update.
