Jumpers & Connectors
Jumper/Connector Function
J1 Front Panel Audio Header
J8 ID LED SW Header
SW1/LED1 ID LED Button / ID LED
J18/J19/J27/J44/J46/J48/J50 4-pin FAN Connector
J20 COM2 Header
J22 IPMB Connector
J23/J40/J55 USB Front Panel Header
J26 Front Fan Connector Reserved for Barebone
J28 / J65 SSI 8-pin CPU1 / CPU0 Power Connector
J57 SSI 4-pin PCIE Power Connector
J43 SSI 24-pin Power Connector
J31 TYAN Module Header
J34 Patsburg Upgrade ROM Module Connector
J36 / J38 Mini SAS Connector
J56 Vertical Type-A USB Connector
J41 Chassis Intrusion Header
J45 Front Panel Header
J49 SATA SGPIO Header for BB HD Board
J51 HDD FAULT Header for BB HD Board
J52 LAN3 LED Header
J58 PSMI Connector
J63/J64 SATA3.0 Connector (SATA1/SATA0)
J62/J61/J60/J59 SATA2.0 Connector (SATA2/3/4/5)
J66 Flash Security Override Header
J67 PCH Software SAS RAID Key Header
JP8 Memory Slot Event Select Jumper
JP9 Clear CMOS Jumper
JP10 ME Firmware Update Jumper
JP11 ME Recovery Mode Jumper
Jumper Legend
OPEN - Jumper OFF
Without jumper cover
CLOSED - Jumper ON
With jumper cover
