TYAN S7055 - Page 42

http://www.tyan.com
42
Recommended Memory Population Table
Single CPU Installed
(CPU0 only)
Quantity of
memory installed
1 2 3 4
CPU0_DIMM_A0
√ √ √ √
CPU0_DIMM_B0
√ √ √
CPU0_DIMM_C0
√ √
CPU0_DIMM_D0
√
NOTE:
1. √ indicates a populated DIMM slot.
2. Use paired memory installation for max performance.
3. Populate the same DIMM type in each channel, specifically
- Use the same DIMM size
- Use the same # of ranks per DIMM
4. Dual-rank DIMMs are recommended over single-rank DIMMs.
5. Un-buffered DIMM can offer slightly better performance than registerd DIMM if
populating only a single DIMM per channel.
6. Always install with CPU0 Socket and DIMM_0 Slot first, following the alphabetical order.
Dual CPU installed (CPU0 and CPU1)
Quantity of
memory installed
2 3 4 5 6 7 8
CPU0_DIMM_A0
√ √ √ √ √ √ √
CPU0_DIMM_B0
√ √ √ √ √ √
CPU0_DIMM_C0
√ √ √ √
CPU0_DIMM_D0
√ √
CPU1_DIMM_A0
√ √ √ √ √ √ √
CPU1_DIMM_B0
√ √ √ √ √
CPU1_DIMM_C0
√ √ √
CPU1_DIMM_D0
√
