3.3.12.1 Console Redirection Settings
Terminal Type
VT-UTF8 is the preferred terminal type for out-of-band management. The next best
choice is VT100+ and then VT100. See above, in Console Redirection Settings
page, for more Help with Terminal Type/Emulation.
VT-UTF8 / VT100 / VT100+ / ANSI
Bits per Second
Select serial port transmission speed. The speed must be matched on the other
side. Long or noisy lines may require lower speeds.
38400 / 9600 / 19200 / 115200 / 57600
Data Bits
8 / 7
Parity
A parity bit can be sent with the data bits to detect some transmission errors. Even:
parity bit is 0 if the num of 1’s in the data bits is even. Odd: parity bit is 0 if the num
of 1’s in the data bits is odd. Mark: parity bit is always 1. Space: parity bit is always
0. Mark and Space parity do not allow for error detection.
None / Even / Odd / Mark / Space
