9
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp.
- 40° C ~ 70° C (-40° F ~ 158° F)
Operating
Environment
In/Non-operating
Humidity
90%, non-condensing at 35° C
RoHS RoHS 6/6 Compliant Yes
Motherboard (1) S7055 Motherboard
Manual (1) Quick Installation Guide
Installation CD (1) TYAN installation CD
I/O Shield (1) I/O Shield
Package Contains
Cable SATA (6) SATA signal cables
TYAN S7055 (S7055AGM3NR-2T [BTO])
Supported CPU
Series
Intel Xeon Processor E5-2600 Series
Socket Type / Q'ty (2) LGA2011
Thermal Design
Power (TDP)
wattage
150W
Processor
System Bus
Up to 8.0/ 7.2/ 6.4 GT/s with Intel QuickPath
Interconnect (QPI) support
Chipset PCH Intel C602
Supported DIMM
Qty
(4)+(4) DIMM slots
DIMM Type / Speed
DDR3/DDR3L 800 / 1066 / 1333 / 1600 RDIMM,
1066 / 1333 / 1600 UDIMM, 1066 / 1333 LRDIMM/
Support DDR3 Unbuffered and Register ECC
Capacity
Up to 256GB RDIMM / 64GB UDIMM / 256GB
LRDIMM
Memory channel 4 Channels per CPU
Memory
Memory voltage 1.5V or 1.35V
PCI-E
(4) PCI-E Gen3 x16 slots (x16 link, slot #7, #5, #3,
#1) / (1) PCI-E Gen2 x8 slot (x4 link, slot #4)
Expansion Slots
PCI (1) PCI 32-bit slot (slot #2)
Recommended
Barebone /
Chassis
4U Barebone FT48-B7055
Port Q'ty (1) GbE port, (2) 10 GbE ports
LAN
Controller Intel 82574L / Intel X540-AT2
Connector (10) SATA; (2) 6G + (8) 3G
Controller Intel C602
Storage SATA
Speed
(2) 6.0 Gb/s (blue color), (4) 3.0 Gb/s (black color)
+ (4) 3.0 Gb/s (mini-SAS connector)
