Recommended Memory Population Table
Single CPU
Installed
(CPU0 only)
Dual CPU
installed
(CPU0 and CPU1)
Quantity of
memory installed
1 2 3 4 6 8 2 3 4 5 6 7 8 10
12
CPU0_DIMM(1)D0
√
√
CPU0_DIMM(2)D1
√ √ √
√ √ √ √
CPU0_DIMM(3)C0
√
√
CPU0_DIMM(4)C1
√ √ √ √
√ √ √ √ √ √
CPU0_DIMM(5)B0
√ √
√ √
CPU0_DIMM(6)B1
√ √ √ √ √
√ √ √ √ √ √ √ √
CPU0_DIMM(7)A0
√ √
√ √
CPU0_DIMM(8)A1
√ √ √ √ √ √ √ √ √ √ √ √ √ √ √
CPU1_DIMM(12)D0
√ √ √
CPU1_DIMM(11)C0
√ √ √ √ √
CPU1_DIMM(10)B0
√ √ √ √ √ √ √
CPU1_DIMM(9)A0
√ √ √ √ √ √ √ √ √
NOTE:
1. √ indicates a populated DIMM slot.
2. Paired memory installation for Max performance.
3. Populate the same DIMM type in each channel, specifically
- Use the same DIMM size
- Use the same # of ranks per DIMM
4. Dual-rank DIMMs are recommended over single-rank DIMMs
5. Un-buffered DIMM can offer slightly better performance than registerd
DIMM if populating only a single DIMM per channel
6. We don't suggest other memory installation.
7. AMD 6100 series CPU doesn't support Quad-ranks U-DIMM
