U-DIMM Module Support
DDR3 Speed/Voltage DDR3 Rank Configuration
1.35v 1.5v
CPU0_DIMM0
(A0, B0, C0, D0)
CPU1_DIMM1
(A1, B1, C1, D1)
CPU1_DIMM0
(A0, B0, C0, D0)
800MHz 800MHz SR and DR SR and DR
800MHz 800MHz SR and DR SR and DR SR and DR
1066MHz 1066MHz SR and DR SR and DR
1066MHz 1066MHz SR and DR SR and DR SR and DR
n/a 1333MHz SR and DR SR and DR
n/a 1333MHz SR and DR SR and DR SR and DR
NOTE:
 UDIMM can support up to 4GB sized DIMM’s
 Maximum of 8GB per channel
 SR and DR UDDR3 module support only
 SR and DR 1.35v Memory MAX speed of 1066MHz in a dual channel
configuration
 SR and DR 1.5v Memory MAX speed of 1333MHz in a dual channel
configuration

SR: Single-rank, DR: Dual-rank
