Tyco DV-3 - Electric Actuation Installation Dimensions

Page 14 of 20
TFP1350
FIGURE 10
2-1/2 INCH (DN65) MODEL DV-3 DELUGE VALVE
— ELECTRIC ACTUATION / NOMINAL INSTALLATION DIMENSIONS —
LEFT VIEW FRONT VIEW
10"
(250 mm)
8-1/4"
(209,6 mm)
12"
(300 mm)
14"
(350 mm)
6-1/4"
(158,8 mm)
5-5/8"
(142,9 mm)
4"
(101,6 mm)
15-3/4"
(400,1 mm)
1-5/8"
(41,3 mm)
MINIMUM CLEARANCE,
*
ADDITIONAL 2" (500 mm)
RECOMMENDED.
**
*
OBSOLETE
