ITEM QTY DESCRIPTION CH 1-1/2 IN. (DN40) 2 IN. (DN50) 3 IN. (DN80) 4 IN. (DN100) 6 IN. (DN150) 8 IN. (DN200)
19 2 FLARE FITTING 90° 1/2” NPT x 1/2” TUBE 545100062 545100062 545100062 545100062 545100062 545100062
20 2 FLARE FITTING 3/4” NPT x 3/4” TUBE 545100063 545100063 545100063 545100063 545100063 545100063
21 2 PIPE PLUG
✓
1/4” 1/4” 1/4” 1/4” 1/4” 1/4”
22 1 PIPE PLUG
✓
1/2” 1/2” 1/2” 1/2” 1/2” 1/2”
23 1 PIPE PLUG
✓
3/4” 3/4” 3/4” 3/4” 3/4” 3/4”
24 2 UNION
✓
1/2” 1/2” 1/2” 1/2” 1/2” 1/2”
25 1 STREET ELBOW
✓
1/4” x 90° 1/4” x 90° 1/4” x 90° 1/4” x 90° 1/4” x 90° 1/4” x 90°
26 1 ELBOW
✓
1/2” x 45° 1/2” x 45° 1/2” x 45° 1/2” x 45° 1/2” x 45° 1/2” x 45°
27 4 ELBOW
✓
1/2” x 90° 1/2” x 90° 1/2” x 90° 1/2” x 90° 1/2” x 90° 1/2” x 90°
28 1 CROSS
✓
1/2” 1/2” 1/2” 1/2” 1/2” 1/2”
29 2 TEE
✓
1/2” 1/2” 1/2” 1/2” 1/2” 1/2”
30 1 REDUCING TEE
✓
1/2” x 1/4” x 1/2” 1/2” x 1/4” x 1/2” 1/2” x 1/4” x 1/2” 1/2” x 1/4” x 1/2” 1/2” x 1/4” x 1/2” 1/2” x 1/4” x 1/2”
31 2 REDUCING TEE
✓
1/2” x 1/2” x 1/4” 1/2” x 1/2” x 1/4” 1/2” x 1/2” x 1/4” 1/2” x 1/2” x 1/4” 1/2” x 1/2” x 1/4” 1/2” x 1/2” x 1/4”
32 2 REDUCING TEE
✓
3/4” x 1/2” x 3/4” 3/4” x 1/2” x 3/4” 3/4” x 1/2” x 3/4” 3/4” x 1/2” x 3/4” 3/4” x 1/2” x 3/4” 3/4” x 1/2” x 3/4”
33 1 REDUCING TEE
✓
3/4” x 3/4” x 3/4” 3/4” x 3/4” x 3/4” 1-1/4” x 1-1/4” x 3/4” 2” x 2” x 3/4” 2” x 2” x 3/4” 2” x 2” x 3/4”
34 1 PIPE NIPPLE
✓
1/4” x CLOSE 1/4” x CLOSE 1/4” x CLOSE 1/4” x CLOSE 1/4” x CLOSE 1/4” x CLOSE
35 1 PIPE NIPPLE
✓
1/4” x 1-1/2” 1/4” x 1-1/2” 1/4” x 1-1/2” 1/4” x 1-1/2” 1/4” x 1-1/2” 1/4” x 1-1/2”
36 5 PIPE NIPPLE
✓
1/2” x CLOSE 1/2” x CLOSE 1/2” x CLOSE 1/2” x CLOSE 1/2” x CLOSE 1/2” x CLOSE
37 4 PIPE NIPPLE
✓
1/2” x 1-1/2” 1/2” x 1-1/2” 1/2” x 1-1/2” 1/2” x 1-1/2” 1/2” x 1-1/2” 1/2” x 1-1/2”
38 1 PIPE NIPPLE
✓
1/2” x 2” 1/2” x 2” 1/2” x 2” 1/2” x 2” 1/2” x 2” 1/2” x 2”
39 2 PIPE NIPPLE
✓
1/2” x 2-1/2” 1/2” x 2-1/2” 1/2” x 2-1/2” 1/2” x 2-1/2” 1/2” x 2-1/2” 1/2” x 2-1/2”
40 1 PIPE NIPPLE
✓
1/2” x 4-1/2” 1/2” x 4-1/2” 1/2” x 4-1/2” 1/2” x 4-1/2” 1/2” x 4-1/2” 1/2” x 4-1/2”
41 1 PIPE NIPPLE
✓
1/2” x 5” 1/2” x 5” 1/2” x 5” 1/2” x 5” 1/2” x 5” 1/2” x 5”
42 1 PIPIE NIPPLE
✓
1/2” x 8-1/2” 1/2” x 8-1/2” 1/2” x 8-1/2” 1/2” x 8-1/2” 1/2” x 8-1/2” 1/2” x 8-1/2”
43 1 PIPE NIPPLE
✓
3/4” x 1-1/2” 3/4” x 1-1/2” 3/4” x 1-1/2” 3/4” x 1-1/2” 3/4” x 1-1/2” 3/4” x 1-1/2”
44 1 PIPE NIPPLE
✓
3/4” x 4-1/2” 3/4” x 4-1/2” 3/4” x 4-1/2” 3/4” x 4-1/2” 3/4” x 4-1/2” 3/4” x 4-1/2”
45 1 TUBING, MRA-1 DRAIN 545100065 545100065 545100066 535002140 535002160 535002180
46 1 TUBING, MC-2 DRAIN 535000220 535000220 535000230 535000240 535000260 535000280
47 1 TUBING, SOLENOID DRAIN 535001020 535001020 535000630 535000640 535000660 535000680
48 1 TUBING ASSY, ALARM TEST INTERCONNECT 535000320 535000320 535000330 535000340 535000360 535000380
49 1 TUBING ASSY, SYSTEM DRAIN 535000420 535000420 535000430 535000440 535000460 535000480
50 1 PIPE NIPPLE
✓
1/2” x 3-1/2” 1/2” x 3-1/2” 1/2” x 4-1/2” 1/2” x 5-1/2” 1/2” x 5-1/2” 1/2” x 6-3/4”
51 1 PIPE NIPPLE
✓
1/2” x 5” 1/2” x 5” 1/2” x 5-1/2” 1/2” x 5-1/2” 1/2” x 5-1/2” 1/2” x 6-1/2”
52 1 PIPE NIPPLE
✓
1/2” x 5” 1/2” x 5” 1/2” x 4-1/2” 1/2” x 5” 1/2” x 7-1/2” 1/2” x 9-1/2”
53 1 PIPE NIPPLE
✓
3/4” x 5” 3/4” x 5” 3/4” x 6” 3/4” x 7” 3/4” x 9” 3/4” x 11-1/2”
54 1 PIPE NIPPLE
✓
3/4” x 4-1/2” 3/4” x 4-1/2” 1-1/4” x 3-1/4” 2” x 3” 2” x 3” 2” x 3”
55 1 PIPE NIPPLE
✓
3/4” x 6-1/2” 3/4” x 6-1/2” 1-1/4” x 5-1/2” 2” x 5” 2” x 6” 2” x 8”
56
2
WATER PRESSURE GAUGE, 300 PSI / 2000 kPa
(AMER/APAC)
923431005 923431005 923431005 923431005 923431005 923431005
2
WATER PRESSURE GAUGE, 20 bar / 2000 kPa
(EMEA)
025500013 025500013 025500013 025500013 025500013 025500013
57 1
AIR PRESSURE GAUGE, 80 PSI / 550 kPa
RETARDED TO 250PSI / 1750 kPa
923431012 923431012 923431012 923431012 923431012 923431012
58 1 LABEL 545003005 545003005 545003005 545003005 545003005 545003005
59 1 LABEL WIRE — — — — — —
A1 1 DV-5 A VALVE
REFER TO TFP1450, TABLE E FOR DV-5A PART NUMBERS.
A2
1
WATERFLOW PRESSURE ALARM SWITCH,
PS10-2 (AMER/APAC)
25710 25710 25710 25710 25710 25710
1
WATERFLOW PRESSURE ALARM SWITCH,
PS10-1 (EMEA)
0260 0260 0260 0260 0260 0260
A3 1 Not Used — — — — — —
A4
1 BUTTERFLY VALVE, G x G 51024A 51021A — — — —
1 BFV-300 BUTTERFLY VALVE, G x G — — 59300G030WS 59300G040WS 59300G060WS 59300G080WS
A5
2 FIGURE 577 RIGID GROOVED COUPLING 57715ACP 57720ACP — — — —
1 FIGURE 577 RIGID GROOVED COUPLING — — 57730ACP 5774 0ACP 57760ACP 57780ACP
A6 1 GROOVE x THREADED OUTLET WELDED TEE 545004000 545004001 — — — —
A7 1
SOLENOID VALVE NORMALLY CLOSED
(SEPARATELY ORDERED)
REFER TO
TFP2180
REFER TO
TFP2180
REFER TO
TFP2180
REFER TO
TFP2180
REFER TO
TFP2180
REFER TO
TFP2180
A8 1 FLARE FITTING 90° 545100100 545100100 545100099 545100100 545100100 545100100
A9 1 FLARE FITTING 90° 1/2” NPT x 1/2” TUBE 545100062 545100062 545100062 545100062 545100062 545100062
A10 1 TUBING ASSY, DIAPHRAGM CHAMBER SUPPLY 540000015 540000020 540000030 540000040 540000060 540000080
Q1 1 MODEL QRS QUICK RELEASE SWITCH 923121001 923121001 923121001 923121001 923121001 923121001
Q2 1 RELEASING PANEL, MODEL PFC-4410RC 20135 20135 20135 20135 20135 20135
Q3 2 BATTERY BACK-UP, MODEL BT-120 20128 20128 20128 20128 20128 20128
Notes:
• CH - Common Hardware
FIGURE 3A (PART 2 OF 2)
DV-5a VALVE - DOUBLE INTERLOCK PREACTION ELECTRIC/ELECTRIC ACUATION TRIM
WITH MODEL QRS ELECTRONIC ACCELERATOR OPTIONAL COMPONENTS
EXPLODED VIEW
