Limited
Warranty
For warranty terms and conditions, visit
www.tyco-fire.com.
Ordering
Procedure
Contact your local distributor for avail-
ability. When placing an order, indi-
cate the full product name and Part
Numbers (P/N).
Sprinkler Assemblies with NPT
Thread Connections:
Specify: Model (specify) ECOH Hori-
zontal Sidewall Sprinkler, SIN (specify),
(specify) temperature rating, (specify)
finish, P/N (specify from Table B)
Sprinkler Wrench:
Specify: W-Type 3 Sprinkler Wrench,
P/N 56 -895-1-001
P/N 51 – XXX – X – XXX
SPRINKLER
TEMPERATURE
RATING
155
155°F (68°C)
(SW-20 Only)
200
200°F (93°C)
(SW-20 or SW-24)
SPRINKLER
FINISH
1 Natural Brass
4
Signal White (RAL9003)
Polyester
9 Chrome Plated
MODEL SIN
072 Model SW-20 TY5332
073 Model SW-24 TY5337
TABLE B
MODEL SW-20 AND SW-24 ECOH HORIZONTAL SIDEWALL SPRINKLERS
WITH 3/4 INCH NPT CONNECTION
PART NUMBER SELECTION
