Ordering
Procedure
Contact your local distributor for avail-
ability.
G1 Sprinkler Guard:
Specify: Model G1 Sprinkler Guard
having a (specify) finish, P/N (specify).
Red Painted . . . . . . . . . . . . . . P/N 56-938-1-001
Zinc Chromate . . . . . . . . . . . . P/N 56-938-9-001
G4 Sprinkler Guard:
Specify: Model G4 Sprinkler Guard
having a (specify) finish, P/N (specify).
Red Painted . . . . . . . . . . . . . . P/N 56-937-1-001
Zinc Chromate . . . . . . . . . . . . P/N 56-937-9-001
G1/S1 Guard with Shield:
Specify: Model G1/S1 Sprinkler Guard
with Shield having a (specify) finish,
P/N (specify).
Red Painted . . . . . . . . . . . . . . P/N 56-938-1-066
Zinc Chromate . . . . . . . . . . . . P/N 56-938-9-066
G4/S3 Guard with Shield:
Specify: Model G4/S3 Sprinkler Guard
with Shield having a (specify) finish,
P/N (specify).
Red Painted . . . . . . . . . . . . . . P/N 56-937-1-066
Zinc Chromate . . . . . . . . . . . . P/N 56-937-9-066
Additonal* Clip Installation Tool:
Specify: Clip Installation Tool for
G1 & G4 Sprinkler Guards,
P/N (56-000-8-597).
* The Clip Installation Tool is included with
orders in original cartons.
Page4of4
TFP780
FIGURE 3
INSTALLATION PROCEDURE
TYCO FIRE PRODUCTS, 451 North Cannon Avenue, Lansdale, Pennsylvania 19446
ADJACENT BARS, PRESS SECOND CLIP
CAREFULLY SPREAD BASE PLATES APART AND FIT
SPRINKLER SHOWN
MODEL G1 GUARD &
SERIES TY-FRB PENDENT
BARS AND SLIDE TOWARD BASE
PLATES
NTIL SN
LOCATION PER TABLE A AND FIGURES 1 or 2
ONTO SPRINKLER AT APPROPRIATE MOUNTING
WITH SPRINKLER PROPERLY INSTALLED,
SWIVEL CLIPS OVER ADJACENT
ADJACENT
BAR
CLIP
PLATES
BASE
TOOL (SHIPPED WITH
SLOT
CLIP FULLY
ENGAGED
FIRST
GUARDS)
ENGAGED
CLIP FULLY
FIRST
CLIP INSTALLATION
BAR
& SERIES TY-L UPRIGHT
WITH MODEL S3 SHIELD
MODEL G4 GUARD
SPRINKLER SHOWN
CLIP
CLIP
TOOL
INSTALLATION
MAY BE
USED
A PLIER
SECOND
ENGAGED
CLIP FULLY
T
WARD BASE PLATES
NTIL F
LLY EN
A
ED
WITH INSTALLATION TOOL APPLIED OVER
CLIP
INSTALLATION
TOOL
CLIP
