TFP357
Page 2 of 6
*
**
**
*
TY-FRB
2-3/8"
(60,3 mm)
3"
(76,2 mm)
MODEL G1
GUARD
2-7/8"
(73,0 mm)
GUARD
BAR
GUARD
BASE PLATE
7/16" (11,1 mm)
NOMINAL MAKE-IN
3-1/2" DIA.
(88,9 mm)
MODEL S2
SHIELD WITH
O-RING
GUARD CLIP
ENGAGED
AGAINST GUARD
BASE PLATES
SPRINKLER
THREAD RELIEF
ENGAGED BY GUARD
BASE PLATES
1/2"
NPT
TY-FRB Sprinkler,
G1 Guard, and
S2 Shield with
O-Ring are
ordered seperately.
Temperature
rating is indicated
on Deector.
Pipe thread
connections per
ISO 7-1 can be
provided on
special request.
**
*
**
*
2-3/8"
(60,3 mm)
3"
(76,2 mm)
MODEL G1/S1
GUARD WITH
SHIELD
2-7/8"
(73,0 mm)
GUARD
BAR
GUARD
BASE PLATE
7/16" (11,1 mm)
NOMINAL MAKE-IN
GUARD CLIP
ENGAGED
AGAINST GUARD
BASE PLATES
SPRINKLER
THREAD RELIEF
ENGAGED BY GUARD
BASE PLATES
1/2"
NPT
TY-FRB Sprinkler
and G1/S1 Guard
with Shield are
ordered seperately.
Temperature
rating is indicated
on Deector.
Pipe thread
connections per
ISO 7-1 can be
provided on
special request.
TY-FRB
FACTORY ASSEMBLED
SHIELD
4" DIA.
(101,6 mm)
**
**
*
*
7/16" (11,1 mm)
NOMINAL MAKE-IN
3-1/2" DIA.
(88,9 mm)
MODEL S2
SHIELD WITH
O-RING
1/2"
NPT
TY-FRB Sprinkler
and S2 Shield
with O-Ring are
ordered seperately.
Temperature
rating is indicated
on Deector.
Pipe thread
connections per
ISO 7-1 can be
provided on
special request.
TY-FRB
2"
(50,8 mm)
SPRINKLER
WRENCH
FLATS
FIGURE 2
SERIES TY-FRB PENDENT (TY323) INTERMEDIATE LEVEL SPRINKLER
WITH S2 SHIELD AND G1 GUARD
FIGURE 1
SERIES TY-FRB UPRIGHT (TY313) INTERMEDIATE LEVEL SPRINKLER
WITH G1/S1 GUARD WITH SHIELD
FIGURE 3
SERIES TY-FRB PENDENT (TY323) INTERMEDIATE LEVEL SPRINKLER
WITH S2 SHIELD
