TYM BT400 User Manual

BACKHOE SPECIFICATIONS
Specifications and design are
s
ubject to change without prior
D
I
K
2'
E
A
J
B
F
H
G
C
J
H
- 9 -
Backhoe Model : BT400
Tractor Model :
T400, T451, T433, T503, T603
A. Digging Deth (two foot flat bottom) 2,400 mm 94.4 "
B. Reach from center line of Swing Pivot 3,460 mm 136.1 "
C. Loading Height (bucket at 60°) 2,040 mm 80.3 "
D. Maximum Leveling Angle 10 ° 10 °
E. Swing Arc 180 ° 180 °
F. Transport Height (maximum) 2,360 mm 92.9 "
G. Transport Overhang 1,280 mm 50.4 "
H. Bucket Rotation 180 ° 180 °
I. Stabilizer Spread (down position) 1,745 mm 68.7 "
J. Stabilizer Spread (up position) 1,180 mm 46.4 "
K. Angle of Departure 21 ° 21 °
Shipping Weight - Backhoe(without bucket) 500 ㎏ 1,102 lbs
Bucket Digging Force 1,477 ㎏ 3,257 lbs
Dipperstick Digging Force 1,000 ㎏ 2,205 lbs
Operating Pressure 168 bar 2,441 psi
Specifications may vary depending on tractor model, tire size and bucket used.
mm inch mm inch mm inch mm inch
B
oom 70 2.756 636 25.039 386 15.197 40 1.575
Bucket 60 2.362 630 24.803 395 15.551 35 1.378
Dipperstick 70 2.756 708 27.874 505 19.882 40 1.575
Swing 60 2.362 398 15.669 223 8.780 35 1.378
Stabilizer 60 2.362 446 17.559 262 10.315 35 1.378
Buckets Bucket
9" Bucket
12" Bucket
16" Bucket
18" Bucket
24" Bucket
36" Bucket
4
1.01 cu. ft.
1.56 cu. ft. 2.02 cu. ft.
1.38 cu. ft.
70 lbs.
1.24 cu. ft. 56 lbs.
1.76 cu. ft. 64 lbs.
Heaped Capacity
3
3
Shipping WeightTeeth Q'TY Struck Capacity
3 0.73 cu. ft. 0.87 cu. ft. 46 lbs.
Rod DIA
CylinderCylinders
Bore DIA Retracted Length Stroke
5 2.11 cu. ft. 2.82 cu. ft. 94 lbs.
6 2.78 cu. ft. 4.00 cu. ft. 114 lbs.
- 9 -
