TYM BT400 - Page 40

MAINFRAME ASSEMBLY
UPDATED : 03. 31. 2009
REF.NO
REF.NO
REF.NO
REF.NO PART.NO
PART.NOPART.NO
PART.NO DESCRIPTION
DESCRIPTIONDESCRIPTION
DESCRIPTION QTY
QTYQTY
QTY I.C
I.CI.C
I.C REMARK
REMARKREMARK
REMARK
1 BT664-11000-01 MAIN FRAME ASS'Y 1
1 BT664-11000-05 MAIN FRAME ASS'Y 1 08.10.07~
2 BT651-52100 CROSS BAR 1
2 BT651-52100-01 CROSS BAR 1 07.07.03~
3 BT664-62100-02 STABILIZER ASS'Y-RH 1
4 BT664-61100-02 STABILIZER ASS'Y-LH 1
5 BT664-61200 FOOT PLATE 2
6 BT651-31600 BRACKET-CUSHION 2
7 1002-B004 CUSHION 2
8 BT651-75110 BUSHING, 405030 2
8 BT651-75110-03 BUSHING, 405030 2 08.10.07~
9 BT664-71100 PIN, φ25-171L 4
10 BT664-71200 PIN, φ25-139L 2
11 BT664-71300 PIN, φ25-175L 2
12 BT664-72800-02 STABILIZER LOCK 2
13 BT664-73120 WASHER 2
14 10121-M1004-90 HEX. BOLT, M10-1.5P 90L 2
15
10316-M1000
WASHER-SPRING, M10
2
- 39 -
15
10316-M1000
WASHER-SPRING, M10
2
16 1002-B005 RUBBER STOP 2
17
BH09-0117 U-BOLT, ∅40,5/16-18 1
18 10121-M0803-50 HEX. BOLT, M8-1.25P 50L 8
19 1021N-M0803 HEX. NUT, M8-1.25P 8
20 1021N-M1004 HEX. NUT LOCK, M10-1.5P 4
21 1202-0361 HEX. NUT, 5/16 4
22 10121-M1606-60 HEX. BOLT-HT, M16-2.0P 60L 4
23 10316-M1600 WASHER-SPRING, M16 4
24 1021N-M1606 HEX. NUT LOCK, M16-2.0P 4
25 10121-M1004-50 HEX. BOLT, M10-1.5P 50L 2
26 10321-M1000 WASHER-PLAIN, M10 4
27 BH07-0113 SPRING 2 Old No.
27 14211-10034 SPRING 2
28 802G0-11900 NIPPLE GREASE, PT1/8 8
29 802G1-11900 NIPPLE GREASE, PT1/8 45˚ 2
